Large-capacity paste packaging machine

The large-capacity paste packaging machine features a collar-style bag-forming mechanism, belt-driven bag pulling, automatic cutting, and other functions. It is designed to handle heavier bagged materials, providing a perfect solution for the quantitative packaging of large-format bagged goods across various industries.

Product Introduction：

This machine is a large-scale, vertical, three-side-sealed, pillow-shaped bag, intermittent packaging machine. It can automatically complete the entire process, including bag forming, metering, filling, sealing, batch number printing, cutting, and counting.

It employs a piston-type filling and metering system, designed for large-volume packaging of liquids and semi-liquids. All components in contact with the product are made of stainless steel and non-toxic, wear-resistant plastic, meeting the requirements for food and pharmaceutical packaging.

Features：

1. Packaging speed can be infinitely adjusted within the rated range.

2. Microcomputer-controlled bag length adjustment: Utilizes coaxial photoelectric encoder control. Bag length is set via a microcomputer, ensuring accurate bag length, convenient adjustment, simple maintenance, and reliable operation.

3. Dual-channel heat sealing temperature control: Temperature can be preset via an intelligent temperature controller, ensuring precise control. Excellent thermal balance guarantees high-quality seals.

4. Photoelectric automatic positioning system: Utilizing proprietary photoelectric positioning technology, it ensures the integrity of the bag pattern for packaging materials printed with color marks.

5. Stepless filling volume adjustment: Employing coaxial photoelectric encoding, stepless adjustment is achieved within the rated range via microcomputer control. The system features a simple structure, precise control, and stable, reliable operation.

Product Parameters：

Model DXD-420A

Filling Method Piston-type filling

Bag Dimensions L200mm, W150mm

Air Pressure 6 kg/cm² 2.5 m³/min

Filling Weight 50–200 g (specify when ordering)

Packaging Accuracy Packaging weight deviation ≤ ±1%

Packaging Speed 25–60 bags/min

Sealing Type Back Sealing

Power Supply 380V/220V, 50–60 Hz

Total Power 4 kW

Total Weight 650 kg

Overall Dimensions 1200 × 900 × 1600 mm

Scope of Application：

Paste bagging machines are primarily used for packaging products in the food, pharmaceutical, personal care, and chemical industries. Examples include peanut butter, sesame paste, ketchup, honey, condensed milk, and cream.
