Automatic powder packaging machine

An automatic powder packaging machine is an automated device designed to automatically execute the entire packaging process for powdered materials—including weighing, bag forming, filling, sealing, and cutting. Widely utilized across industries such as food, pharmaceuticals, chemicals, and daily consumer goods, it serves as a critical piece of equipment in modern production lines for enhancing efficiency and ensuring packaging quality.

Product Introduction：

The automatic small-bag powder packaging machine is specifically designed for the small-bag packaging of powdered materials. It operates fully automatically through a screw feeder system and an intelligent control system. The main body of the equipment is typically constructed of 304 stainless steel, which meets hygiene standards and features dust-proof and leak-proof properties, making it suitable for industries with high hygiene requirements.

Features：

*The system is microprocessor-controlled. A sensor signal is processed and configured by the microprocessor to synchronize the operation of two stepper motors, controlling bag length, discharge position, discharge speed, and positioning. It also performs automatic fault diagnosis and displays results on the screen. A series of operations—including bag forming, discharge and inflation, counting, sealing, coding, limit-based shutdown, and batch cutting—are all performed automatically.

Product Parameters：

型号:

Model:

DXD-240F

DXD-320F

DXD-420F

制袋尺寸:

Packingag Size:

长（L）30~180mm宽(W)30~120mm

Length (L) 30–180 mm; Width (W) 30–120 mm

长（L）30~200mm宽(W)30~160mm

Length (L) 30–200 mm; Width (W) 30–160 mm

长（L）30~220mm宽(W)30~180mm

Length (L) 30–220 mm; Width (W) 30–180 mm

制袋方式

Packingag Shape

三边封/四边封/背封

Three or four side seal, or backside seal

三边封/四边封/背封

Three or four side seal, or backside seal

三边封/四边封/背封

Three or four side seal, or backside seal

计量范围:

Measuring：

1-50g

5-100g

20-500g

计量方式：

Measurement methods：

螺杆计量

Screw metering

螺杆计量

Screw metering

螺杆计量

Screw metering

生产能力：

Metering pump：

40–70 袋/分

40–70 bags/min

20–45袋/分

20–45 bags/min

15–25 袋/分

15–25 bags/min

总功率：

Total Power：

2.1KW

2.4KW

2.6KW

整机重量：

Machine Weight：

250KG

280KG

320Kg

外型尺寸：

Product dimensions：

860X680X1750mm

860X780X1800mm

Scope of Application：

*Suitable for packaging various non-sticky powders in the food industry, including those used in food, daily chemicals, seasonings, and pharmaceuticals. Examples include milk powder, soy milk powder, starch, flour, seasoning powder, coffee powder, protein powder, meal replacement powder, lotus root powder, sesame paste, traditional Chinese medicine powder, health supplement powder, pesticide powder, veterinary drugs, feed additives, dyes, pigments, laundry detergent, and facial mask powder.
