Product Introduction：

The fully automatic granule weighing filling and capping line is a high-precision automated packaging system specifically designed for granular, small-piece, and irregular materials. It utilizes load cells for real-time measurement and automatically performs a series of processes, including bottle sorting, weighing and filling, capping/sealing, and labeling. Its core value lies in using weight as the measurement standard, fundamentally overcoming the measurement errors caused by variations in material density and particle size that are common in volumetric filling. Filling accuracy can be consistently maintained at  ±0.5%, making it widely used for the bottling and canning of granular materials in industries such as food, pharmaceuticals, chemicals, and agriculture.

Features：

1. High-precision weighing and metering for accurate and stable filling

Compared to traditional volumetric filling, gravimetric filling uses actual weight as the measurement standard. It is not affected by factors such as changes in material density, uneven particle size, or differences in flowability. Filling accuracy generally ranges from ±0.2% to ±0.5%, with some high-end models achieving accuracy as high as ±0.1%. The equipment utilizes highly stable, high-precision load cells, combined with real-time feedback and compensation from the PLC control system, to ensure highly consistent fill volumes for every bottle or can.

2. Multi-pan weighing system, balancing high speed and precision

The equipment employs four-pan, ten-pan, or fourteen-pan weighing configurations. Through algorithms, it automatically selects the combination of weighing pans closest to the target weight for dispensing, achieving high-speed filling while maintaining high precision. Common models achieve filling speeds of 20–60 bottles per minute, while configurations with a 10-pan combination scale can reach 30–50 cans per minute.

3. High Degree of Automation and Integrated Line Operation

The equipment features a PLC control system paired with a touchscreen HMI, offering intuitive and convenient operation. Key functions include:

No-bottle, no-filling; no-cap, no-capping: Detected via photoelectric sensors to prevent material waste and idle operation

Fault self-diagnosis and alarms: Automatically triggers an alarm and indicates the fault location when abnormalities occur

Recipe memory function: Stores multiple sets of product process parameters, allowing one-click retrieval when switching products

Automatic counting and data logging: Facilitates production management and statistical analysis

Product Parameters：

Weighing Method    4-pan/10-pan/14-pan electronic combination scale

Filling Range    30–2000 g (typical)

Filling Accuracy    ±(0.2%–0.5%)

Filling Speed    20–60 bottles/minute; Canning line: 30–50 cans/minute

Number of Filling Heads    4–10 heads (customizable)

Applicable Bottle/Can Diameter    45–85 mm (customizable)

Applicable Bottle/Can Height    30–180 mm (customizable)

Suitable Cap Diameter    38–70 mm

Capping Torque    3–10 Nm (adjustable)

Control System    PLC + Touchscreen HMI

Power Supply/Power    AC 380 V, 50–60 Hz; Power: 1.2 kW–3.5 kW (main unit)

Total Weight    600–1500 kg

Scope of Application：

Food Industry    Chicken bouillon, MSG, coffee, tea, dried fruits, roasted snacks, nuts, candy, chocolate, sunflower seeds, peanuts, puffed snacks, snack foods, mixed grains, rice, cereals, seasonings, etc.

Pharmaceutical Industry    Granular pharmaceuticals, traditional Chinese herbal slices, health supplement granules, capsules, tablets, solid beverages, etc.

Chemical Industry    Plastic pellets, chemical fertilizers, animal feed, activated carbon, laundry detergent, toner, pesticide granules, etc.

Agricultural Industry    Seeds, grains, and other crops

Consumer Goods Industry    Laundry detergent, table salt, monosodium glutamate, granulated sugar, and other powdered/granular consumer goods
