Diaphragm Pump Filling Machine

Product Introduction：

A diaphragm pump filling machine utilizes the rotational motion of an electric motor to drive a mechanical mechanism that causes the diaphragm inside the pump to move back and forth. This compresses and expands the air within the pump chamber (a fixed volume). Under the action of a check valve, positive pressure is created at the discharge port (the actual output pressure depends on the resistance at the discharge port and the pump’s characteristics), while a vacuum is created at the suction port, thereby generating a pressure differential between the pump and atmospheric pressure. Driven by this pressure differential, water is drawn into the inlet and discharged through the outlet. Under the kinetic energy transmitted by the motor, water is continuously drawn in and discharged, resulting in a relatively stable flow rate.

Features：

1. No oil seals are required, and the interior is oil-free, ensuring that the pumped liquid remains uncontaminated.

2. The pump housing is separated from the motor; even after prolonged use, liquid will not seep into the motor and cause malfunctions, thereby significantly extending the pump’s service life.

3. With excellent sealing performance, the pump features fast and stable self-priming, eliminating the need for manual water addition.

Product Parameters：

Product Name:	1 head filling machine	2 heads filling machine	4 heads filling machine	6 heads filling machine	8 heads filling machine
Voltage:	110V/220V	110V/220V	110V/220V	110V/220V	110V/220V
Power:	50W	100W	200W	300W	400W
Max Pump Flow Rate：	4L/Min	4L/Min	4L/Min	4L/Min	4L/Min
Max Suction Head：	2M	2M	2M	2M	2M
Accuracy（ml）:	±1%	±1%	±1%	±1%	±1%
Machine Size (cm):	302814	343014	393516	393522	704029
Unit Weight（kg）:	4KG	5.6KG	9KG	11KG	21KG
Package Size(cm)：	373118	383618	404122	454131	765137
Package Weight(kg):	5KG	6KG	10KG	13KG	28KG
Filling Range(ml):	3ML-1000ML	3ML-1000ML	3ML-1000ML	3ML-1000ML	3ML-1000ML
Power-Off Memory:	Yes	Yes	Yes	Yes	Yes
Anti-Drip Feature:	Yes	Yes	Yes	Yes	Yes

Application Cases：

The machine operates with some noise, and the stretching of the diaphragm causes some agitation of the liquid; therefore, it is not suitable for filling foamy liquids. It is designed for medium- to low-viscosity liquids that are non-corrosive, free of strong acids or alkalis, and contain no solid particles (such as disinfectants, cooking oil, food products, and cosmetics).
