Product Introduction：

The Semi-Automatic Single-Head Sauce Filling Machine is a semi-automatic filling device suitable for filling various highly fluid pastes and liquid materials. Widely applicable across the pharmaceutical, daily chemical, food, pesticide, and specialized industries, it serves as an ideal piece of fluid filling equipment.

Features：

1.  All parts in contact with the material are constructed from 304 stainless steel, complying with GMP requirements.

2.  Both the filling volume and filling speed can be freely adjusted.

3.  Operation can be initiated via a foot pedal or by selecting the automatic mode for continuous filling.

4.  The filling system features a quick-release design, facilitating easy disassembly and cleaning after use.

5.  All pneumatic components utilized are high-quality domestic brands.

6.  Equipped with a PTFE (Teflon) piston and food-grade silicone sealing rings.

7.  The filling head features an anti-drip design to prevent leakage.

8.  Offers high filling speed and high filling accuracy.

9.  The design can be customized to accommodate the specific characteristics of the material being filled.

10. Facilitates uniform mixing of the material, ensuring smooth and efficient filling.

Product Parameters：

Model: G1WGD100-5000

Voltage: AC 220/110V, 50-60Hz

Power: 250W

Required Air Compressor: 0.4–0.6 MPa, 1.5 kW, 65 L

Filling Speed: 4–18 bpm (depending on filling volume)

Filling Accuracy: ±1%

Available Filling Volumes: 10–100 ml, 30–300 ml, 50–500 ml, 100–1000 ml, 1200–1500 ml, 500–2500 ml, 1000–5000 ml

Scope of Application：

Suitable for filling ketchup, peanut butter, condiments, jams, as well as materials in various industries that require agitation during the filling process.
