Single-head liquid filling machines

Single-head liquid filling machines are mainly used for quantitative dispensing of various paste-like cosmetics, food, pharmaceuticals, and other free-flowing liquids.

Product Introduction：

The horizontal pneumatic filling machine operates entirely under compressed air control. Thanks to its pneumatic control system and specialized three-way positioning mechanism, it achieves exceptional filling precision—maintained within a tolerance of 1‰—while offering simple, user-friendly operation and a low failure rate. Suitable for use in the pharmaceutical, daily chemical, food, pesticide, and specialized industries, it serves as an ideal solution for filling fluid products; its ergonomic design is specifically tailored to meet the exacting standards of modern enterprises.

Features：

1.Material-Contacting Parts: 304 Stainless Steel

2.Pneumatic Components: Airtac

3.Volume Adjustment via Visible Digital Display

Product Parameters：

Model:	GZW-100	GZW-300	GZW-500	GZW-1000	GZW-2000	GZW-5000
Air Pressure:	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa
Air Consumption:	0.1m³/Min	0.1m³/Min	0.1m³/Min	0.1m³/Min	0.15m³/Min	0.18m³/Min
Filling Range:	10-100ml	30-300ml	50-500ml	100-1000ml	300-2500ml	1000-5000ml
Power：	20W	20W	20W	20W	20W	20W
Accuracy (ml):	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%
Machine Dimensions (cm):	1053642	1053642	1053642	1053642	125×42×45	125×42×45
Machine Weight (kg):	34KG	34.5KG	35KG	35.5KG	54KG	56KG
Packaging Dimensions(cm)：	1204037	1204037	1204037	1204037	1455242	1455242
Packaging Weight (kg):	36KG	37KG	37.5KG	38KG	58KG	60KG

Scope of Application：

The scope of application for pneumatic liquid filling machines primarily focuses on liquids ranging from low to medium viscosity. The specific classifications are as follows:

1. Applicable Material Types

Pneumatic liquid filling machines are ideally suited for filling liquids that are free of particulates and possess good to moderate fluidity:

Low-Viscosity Liquids (Aqueous Solutions):

Examples include: mineral water, spirits, beverages, vinegar, soy sauce (low consistency), medical alcohol, disinfectants, and pesticides.

Medium-to-High Viscosity Liquids (Semi-fluids/Pastes):

This represents a particular strength of pneumatic filling machines (specifically the piston-type models). Examples include: shampoo, body wash, cooking oil, ink, paint, etc.
