Product Introduction：

The JX-60 Pneumatic Gripper Automatic Capping Machine is specifically designed for capping irregularly shaped bottle caps, perfume bottle caps, and similar products. The machine utilizes a pneumatic gripper mechanism controlled by a servo motor to evenly tighten the caps onto the bottles.

Features：

* Features PLC control and a touchscreen interface.

* Pneumatic clamping mechanism for lids, with servo motor-driven capping for consistent force.

* Aluminum alloy and stainless steel construction, meeting relevant industry hygiene standards.

Product Parameters：

Model: JX-60

Power Supply: 220V/110V 50-60Hz

Power: 800W

Production Capacity: 18-35 bottles/minute (depending on cap shape and size)

Bottle Diameter: 30-150mm

Bottle Height: 40-220mm

Cap Diameter: 18-60mm

Machine Dimensions: 1500 x 610 x 1750 mm (L x W x H)

Machine Weight: 145 kg

Packaging Dimensions: 1650 x 740 x 1890 mm (L x W x H)

Packaging Weight: 230 kg

Scope of Application：

Widely used for various nozzle caps, perfume bottle caps, essential oil bottle caps, cosmetic bottle caps, and more.
