Product Introduction：

The glass bottle tracking vacuum capping machine is a specialized piece of equipment designed for tightly securing tinplate caps onto glass bottles. It offers high efficiency, versatility, and is safe and easy to operate.

This model is available in single-head and double-head configurations. Customization is optional upon request.

Features：

· Features an integrated automatic vacuum-sealing and capping system for a high degree of automation;

· Capping torque and vacuum levels can be customized to meet specific requirements, ensuring that vacuum standards* are met;

· Suitable for capping a wide variety of round bottles, offering strong compatibility;

· Constructed with stainless steel for easy adjustment of all components;

· Equipped with electrical and pneumatic components from internationally renowned brands to ensure stable, reliable, and durable performance.

Product Parameters：

 Single-Head Tracking Vacuum Capping Machine Specifications

Production Capacity: 28–30 bottles/min

Internal Bottle Pressure: ≤-67 kPa

Tightening Torque: Adjustable               Bottle Height: 60–140 mm

Pneumatic Components: Niulide             Operating Air Pressure: 0.4 MPa–0.6 MPa

Operating Voltage: 220 V               Vacuum Pump:  0.75 W

Drive Motor: Domestic Motor

Servo Positioning Motor: Domestic Xinjie

Conveyor: Linear stainless steel chain conveyor.

Equipment Dimensions: 2800 × 1000 × 2050 mm

Scope of Application：

The follow-up vacuum capping machine is a new type of vacuum capping equipment that integrates advanced electromechanical control technology and manufacturing processes. Thanks to its unique and innovative design concept, this automatic vacuum capping machine is gaining popularity among an increasing number of users. It is widely used in glass jar packaging production lines for seafood, condiments, *food products, pickles, jams, honey, and other food items, as well as in the health supplement and pharmaceutical industries.
