2-head pneumatic paste filling machine

The 2-head pneumatic paste filling machine is mainly used for quantitative dispensing of various paste-like cosmetics, food, medicines and other free-flowing liquid pastes.

Product Introduction：

The dual-head pneumatic paste filling machine is a highly efficient, precise, and safe semi-automatic filling solution. Featuring pneumatic drive and a dual-head synchronous design, it is particularly well-suited for the metered filling of pastes and high-viscosity materials. It is widely used in industries such as cosmetics (e.g., face creams, toothpaste), pharmaceuticals (e.g., ointments, creams), food (e.g., jams, sauces), and chemicals (e.g., lubricants, adhesives). Reliable in performance and easy to clean, it is an ideal choice for small- to medium-volume production and laboratory use.

The horizontal pneumatic paste filling machine is fully controlled by compressed air. Thanks to its pneumatic control system and specialized pneumatic three-way positioning mechanism, it achieves high filling accuracy within 1‰, is simple and user-friendly to operate, and has a low failure rate. Suitable for the pharmaceutical, personal care, food, pesticide, and specialty industries, it is the ideal equipment for filling fluids. Its user-friendly design better meets the requirements of modern enterprises.

Features：

1.Material-Contacting Parts: 304 Stainless Steel

2.Pneumatic Components: Airtac

3.Volume Adjustment via Visible Digital Display

Product Parameters：

Model:	GZW-100	GZW-300	GZW-500	GZW-1000	GZW-2000	GZW-5000
Air Pressure:	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa	0.6-0.8Mpa
Air Consumption:	0.1m³/Min	0.1m³/Min	0.1m³/Min	0.1m³/Min	0.15m³/Min	0.18m³/Min
Filling Range:	10-100ml	30-300ml	50-500ml	100-1000ml	300-2500ml	1000-5000ml
Power：	50W	50W	50W	50W	50W	50W
Accuracy (ml):	±1	±1	±1	±1	±1	±1
Machine Dimensions (cm):	1054242	1054242	1054242	1054242	125×54×45	125×54×45
Machine Weight (kg):	42KG	43KG	45KG	46KG	68KG	70KG
Packaging Dimensions(cm)：	1204837	1204837	1204837	1204837	1455842	1455842
Packaging Weight (kg):	48KG	49KG	51KG	53KG	72KG	78KG

Scope of Application：

Suitable for the pharmaceutical, personal care, food, pesticide, and specialty industries, this equipment is ideal for filling high-viscosity fluids. Since the machine operates without electricity, it offers enhanced safety, and its user-friendly design better meets the needs of modern enterprises;

1. Personal Care Industry

This is one of the most common application areas for paste filling machines. It is suitable for filling various daily cleaning and personal care products:

Hair and Body Care: Shampoo, body wash, conditioner, facial cleanser, hand soap.

Skin Care: Face cream, lotion, sunscreen, body lotion, face mask paste.

Household Cleaning: Laundry detergent, dish soap, floor cleaner (high-viscosity type), windshield washer fluid (thick type).

2. Food Industry

Used for filling various flowable semi-liquid foods, typically requiring equipment that complies with food hygiene standards (such as 304 or 316L stainless steel):

Condiments: Ketchup, chili sauce, peanut butter, sesame paste, broad bean paste, salad dressing, jam, honey.

Grains and Oils: Edible oil (high viscosity), lard, shortening.

Others: Condensed milk, syrup, concentrated fruit juice (high viscosity).

3. Pharmaceutical Industry

Topical preparations: Ointments (e.g., erythromycin ointment), creams, gels, hemorrhoid ointments, dermatitis ointments.
