Double-head lip gloss filling machine

The double-head lip gloss filling machine is suitable for filling high-viscosity liquids, pastes, and similar materials—such as lip gloss, mascara, liquid lipstick, and liquid concealer.



Product Introduction:

The dual-head lip gloss filling machine is suitable for filling high-viscosity liquids and pastes such as lip gloss, mascara, lip tint, and concealer.

Features:

This machine utilizes a piston-type metering valve filling system, ensuring minimal metering error.

It offers three filling modes: manual, automatic, and foot-operated, suitable for various filling frequencies such as machine setup, mass production, and cleaning.

The small turntable features a lift-and-fill mechanism, with the turntable rotation interval adjustable via the display screen, eliminating the need for operators to maintain a specific filling speed. The lift-and-fill mechanism accommodates packaging materials of varying lengths.

The nozzles are equipped with a suction mechanism to prevent material residue, and the metering valves and tubing are easy to disassemble and clean.

The double-walled, pressurized material tank features a pressurization function, making it suitable for materials with poor flowability or high viscosity. It also includes a venting function to prevent air explosions during filling.

The bottle clamping mechanism uses adjustable clamps, allowing it to accommodate packaging materials of various thicknesses and shapes.

Product Parameters:


Power Supply:

220V/ 50Hz

Power:

2.3kw

Air Supply:

0.2-0.6Mpa

Dimension(LxWxH):

610*810*1810MM

Barrel volume:

20L

Filling range:

1-20ml

Filling   accuracy:

±0.1ML

Production   capacity:

1600-2400 branch / hour

Net weight(kg):

120kg

Body material:

SUS304


Scope of Application:

This machine is suitable for filling high-viscosity liquids and pastes such as lip gloss, mascara, lip lacquer, and concealer.
