Mascara Filling Machine

The mascara filling machine is primarily designed for the quantitative filling of cosmetic products—such as dermal fillers, mascara, lip gloss, and liquid or cream foundations. It utilizes a pressurized filling mechanism within the material hopper to ensure uniform pressure distribution on the product during the filling process, thereby enhancing the flowability of the raw materials.



Product Introduction:

Pressurized filling machines are primarily used for the precise filling of cosmetic ingredients such as hydrating serums, mascara, lip gloss, and liquid foundation (liquid/cream). The pressurized filling process within the hopper ensures that the material is subjected to uniform pressure during filling and enhances the flowability of the product. The piston-based volumetric filling method allows for precise setting of the desired volume with minimal error, meeting customer requirements. The machine is simple to operate and easy to clean, offering significant practicality and benefits for users handling a wide variety of filling products.

Features:

Adopting the way of adding air pressure in the barrel for filling. It can fill mascara, lip gloss,hydrafacial, and high viscosity liquid, paste and other raw materials.

Adopting piston type filling method, small quantitative error. It is easy to change the quant-itative valve and pipeline. Nozzle with suction device, not easy to residual material.

The injection speed and pumping speed can be adjusted, and the filling methods are foot-operated (manual) and automatic.

Equipped with a filling counter for easy production statistics.

Product Parameters:


Power supply

220V/   50Hz

Installation   requirements

220VPower supply、Air supply

Power

100W

Cylinder

TGC50*75

Air supply

0.3-0.6Mpa

Barrel volume

18L

Barrel pressure   resistance

6Kg/CM²

Filling range

1~20ml

Filling accuracy

±0.1ML

Production capacity

1200~1800/小时

Body material

tainless steel(SUS304)

Net weight<kg>

60kg

Dimensions (LxWxH)

410*770*1550mm


Scope of Application:
