Product Introduction：

Unlike traditional intermittent filling methods, the core advantage of the fully automatic four-head tracking paste filling machine lies in its “dynamic synchronization” technology. It enables the filling heads to precisely “track” and complete the filling process while the conveyor belt continues to run. This continuous operation mode fundamentally eliminates time losses caused by equipment start-up and shutdown, resulting in an efficiency increase of over 30% compared to traditional equipment. It represents a new solution for achieving high-efficiency, stable filling.

Features：

High Efficiency: The conveyor belt operates continuously without stopping, and the filling process is completed in a single, seamless motion, resulting in production efficiency far exceeding that of traditional models.

Outstanding Accuracy: Dynamic filling combined with high-precision servo pumps typically achieves filling accuracy of ±0.5% to ±1%.

Stable Operation: Servo motors control the movement of the filling heads, ensuring stability and consistency even during high-speed operation.

Flexible Compatibility: Changing product configurations requires only selecting a recipe on the touchscreen; the switch can be completed in 20–30 minutes, accommodating a wide range of bottle shapes and materials.

Strong Material Adaptability: Capable of handling everything from liquid solutions to high-viscosity creams and pastes containing particles, effectively solving the challenges of filling high-viscosity materials.

High-Quality and Hygienic: The entire machine is constructed from 304/316L stainless steel, compliant with GMP standards. Filling nozzles are equipped with anti-drip caps and quick-connect sanitary fittings for easy disassembly and cleaning.

Intelligent Management: Parameter settings and recipe storage are managed via PLC and touchscreen, enabling “one-touch setup.” Select models also feature intelligent detection functions such as low-material alerts and no-bottle-no-fill detection.

Product Parameters：

Number of filling heads: 4

Filling range: 100 ml – 5000 ml (pump selected based on capacity)

Filling accuracy: ±1%

Filling Speed    Approx. 25–83 bottles/minute (depending on product and bottle type)

Dosing Method    Servo-driven piston pump or rotary pump

Control System    PLC + Touchscreen (brands available: Siemens, Xinjie, etc.)

Operating Pressure    0.6–0.8 MPa

Machine Construction    Frame: SUS304 stainless steel; Product-contact parts: SUS304/316L stainless steel

Power Supply/Power    380V / Three-phase five-wire, total power approx. 7 kW

Dimensions    2500 × 1300 × 1650 mm

Scope of Application：

Personal Care Industry: Various high-viscosity personal care products such as shampoo, body wash, conditioner, and laundry detergent.

Food Industry: Various sauces, honey, cooking oil, and paste-like condiments.

Pharmaceutical Industry: Medications requiring high levels of cleanliness, such as ointments, creams, and syrups.

Chemical Industry: Greases, adhesives, paints, etc.

Cosmetics Industry: Lotions, serums, creams, essential oils, etc.
